Product Summary

The LQP03TN22NH00D is a Chip Inductor.

Parametrics

LQP03TN22NH00D absolute maximum ratings: (1)Inductance: 22nH ±3%; (2)Test Frequency: 500MHz; (3)Rated Current: 140mA; (4)Max. of DC Resistance: 2.55ohm; (5)Q (min.): 11; (6)Test Frequency: 500MHz; (7)Self Resonance Frequency (min.): 2800MHz.

Diagrams

LQP03TN22NH00D Dimensions

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LQP03TN22NH00D
LQP03TN22NH00D
Murata
RF Inductors 22 NH 3%
Data Sheet
0-1: $0.17
1-100: $0.13
100-500: $0.09
500-1000: $0.08
