LTC1872ES6#TRPBF

Constant Frequency Current Mode, Step-Up DC/DC Controller, SOT23-6, Low Quiescent Current 270μA

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.10~2.00 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.10~2.00

PartNumber:: LTC1872ES6#TRPBF

Brand:: Linear Technology - Linear | Pack: SOT | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. jamby's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-16

From Other Seller

Part Number:LTC1872ES6#TRPBF
US $0.10 - 2.00
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
LM64P101

US $240.00 - 300.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LTC1872ES6#TRPBF is a constant frequency current mode step-up DC/DC controller providing excellent AC and DC load and line regulation. The device incorporates an accurate undervoltage lockout feature that shuts down the LTC1872ES6#TRPBF when the input voltage falls below 2.0V. The applications of the LTC1872ES6#TRPBF are Lithium-Ion-Powered Applications, Cellular Telephones, Wireless Modems, Portable Computers, Scanners.

Parametrics

LTC1872ES6#TRPBF absolute maximum ratings: (1)Input Supply Voltage (VIN):–0.3V to 10V; (2)SENSE–, NGATE Voltages:–0.3V to (VIN + 0.3V); (3)VFB, ITH/RUN Voltages:–0.3V to 2.4V; (4)NGATE Peak Output Current (<10μs):1A; (5)Storage Ambient Temperature Range:–65℃ to 150℃; (6)Operating Temperature Range:–40℃ to 85℃; (7)Junction Temperature:150℃; (8)Lead Temperature (Soldering, 10 sec):300℃.

Features

LTC1872ES6#TRPBF features: (1)High Efficiency: Over 90%; (2)High Output Currents Easily Achieved; (3)Wide VIN Range: 2.5V to 9.8V; (4)VOUT Limited Only by External Components; (5)Constant Frequency 550kHz Operation; (6)Burst ModeTM ; (7)Operation at Light Load; (8)Current Mode Operation for Excellent Line and Load Transient Response; (9)Low Quiescent Current: 270μA; (10)Shutdown Mode Draws Only 8μA Supply Current; (11)±2.5% Reference Accuracy; (12)Tiny 6-Lead SOT-23 Package.
