Product Summary

The LM336-5.0 is a 5.0V reference diode.

Parametrics

LM336-5.0 absolute maximum ratings: (1)Reverse Current: 15mA; (2)Forward Current: 10mA; (3)Storage Temperature: -60℃ to +150℃; (4)Operating Temperature Range: -55℃ to +150℃.

Features

LM336-5.0 features: (1)Adjustable 4V to 6V; (2)Low temperature coefficient; (3)Wide operating current of 600 μA to 10 mA; (4)0.6 dynamic impedance; (5)± 1% initial tolerance available; (6)Guaranteed temperature stability; (7)Easily trimmed for minimum temperature drift; (8)Fast turn-on; (9)Three lead transistor package .

Diagrams

LM336-5.0 Connection Diagrams
